Description
This is a DC-DC Power Supply Converter Buck Module with a voltage range of 15-35V to 12V, an output power of 36W, a conversion efficiency of more than 90%, a very low calorie count, a short circuit, and overcurrent protection.
Specifications
- Module Properties: non-isolated buck module (BUCK)
- Rectification: synchronous rectification
- Minimum pressure: 2V
- Input voltage: DC 24V (17V–35V)
- Output voltage: 12V
- Output Current: 3A
- Output Power: 36W
- Conversion efficiency: 90%
- Output ripple: 50mV (maximum) 20 m-bandwidth
- Full load temperature rise: 50 °C
- Load regulation: ± 1%
- Voltage regulation: ± 2%
- Dynamic response speed: 5%, 200 uS
- Operating Temperature: Industrial (-40°c to +85°c) ( If ambient temperature exceeds 40°c, lower power use or enhance heat dissipation.)
Features
- Overcurrent protection
- Short-circuit protection
- Input Reverse Polarity Protection: None (Please use the series diode at the input port.)
- Waterproof design
- Waterproof full-potting
- Small size: 58x40x22mm
- 1 x DC/DC Converter
